3130-362 RAE | Parallel Shaft Gearmotor – 90VDC, 32 RPM Place Order

3130-362 RAE | Parallel Shaft Gear Motor – 90VDC, 32 RPMDescription1/8HP, 32 RPM90 Volts DC, 1.58 FLA220 Output Torque (Inch pounds)Shaft: 5/8 x 1.25 inch, keyedGear ratio: 58:1Enclosure rating: IP55The GIL200 Series Gearbox, when matched with the appropriate RAE motor, provides high output torque in a compact, rugged diecast parallel shaft gearmotor design• Gearbox Designed to AGMA Standards• Oil Filled• Needle Bearings (Gearbox) • High Energy Ceramic Magnets• Double Shielded Ball Bearings (Motor)• Dynamically Balanced Armature• Reversible Design• 36” “Cord• TENV Design• Externally Replaceable Brushes• Auto-Hook Tang Type Commutator • Class “F” InsulationCross References – This motor is a suggested replacement for the following motors. RPM, amps, shaft length, etc may not be exact, please double check your application and mounting requirement.Leeson M1125070WEG GH2006Dayton 4Z383Bodine 4155Baldor GPP12556Bison 011-336-2060RAE 3130362
