Sale!
U.S. Motors 8D15P3C Severe Duty & IEEE 841 Three Phase TEFC Horizontal - Footed Motor Save Now
Home / Nema & Tefc Motors / U.S. Motors 8D15P3C Severe Duty & IEEE 841 Three Phase TEFC Horizontal – Footed Motor Save Now

U.S. Motors 8D15P3C Severe Duty & IEEE 841 Three Phase TEFC Horizontal – Footed Motor Save Now

Original price was: $2,662.80.Current price is: $1,065.12.

For orders under $60.00, a shipping fee of $9.99 applies.
Fast delivery, satisfaction guaranteed.
Secure Payment.
SKU: SK0050966 Category: Tag:
Share

The U.S. Motors 8D15P3C is a severe duty and IEEE 841 rated three phase TEFC (Totally Enclosed Fan Cooled) horizontal footed motor. This motor is designed for continuous duty applications and is ideal for use in demanding environments.

  • Powerful 15 horsepower capacity
  • Operates at 1200 RPM
  • Designed for 460 voltage rating

Product Highlights

This motor delivers reliable performance and efficiency in severe duty applications.

Product Information

Standard Information

  • Brand: U.S. Motors
  • Part Number: 114638196

Technical Specifications

  • Voltage Rating: 460
  • Frequency: 60 Hz
  • Full Load Amps: 18.5
  • Full Load Efficiency: 91.7 %
  • Phase: Three Phase
  • RPM: 1200
  • Frame: 284T
  • Enclosure Designation: TEFC – Totally Enclosed Fan Cooled
  • Weight: 340.0 LB
  • Mounting: Horizontal – Footed
  • Frame Material: Cast Iron
  • Duty: Continuous Duty
  • Insulation: F
  • Full Load RPM: 1185 rpm
  • Poles: 6
  • Motor Application: Severe Duty
